Ambient Air Cleaner

The Ambient Air Cleaner is a commercial-grade air filtration system that is highly effective at removing ambient pollutants without the need for external ducting, or make-up air. These low-maintenance filtration systems can be conveniently mounted in the desired ceiling location without taking any floor space, and in certain applications can be mounted on a stand. Typically used in locations where outside ventilation cannot suffice, ambient air cleaners are utilized to remove toxins, pollutants, and contaminants from the atmosphere.

700 Series


Loading the player...

700 Series Ambient Air Collector Specifications

    Cabinet Dimensions:     Cabinet Material:
     - 32 5/8"W x 24 3/4"D x 14.5"H      - 16 ga. Carbon Steel, Powder Coated
    Air Volume: Up to 100 CFM     Total Weight: 132 - 160 lbs. (Varies depending on filter media installed)
    Motor: Fractional Horsepower 3/4

   Available Filter Efficiencies:

   HEPA Filter - Up to 99.97% efficient on particles down to 0.3 microns in size.
   ASHRAE Filter - Up to 95% efficient on particles down to 0.5 microns in size.
   ULPA Filter - Up to 99.9995% efficient on particles down to 0.12 microns in size.
   Activated Carbon & Specialty-Blended Filters - Efficiency varies per chemical.

   Air Volume:

   HEPA: Up to 600 CFM
   ASHRAE: Up to 900 CFM
   (2) ASHRAE: Up to 715 CFM
   8lb. CARBON: Up to 800 CFM
   16lb. CARBON: Up to 600 CFM
   HEPA/8lb. CARBON: Up to 480 CFM

   Electrical:    Sound Level:
    115/1/60, 4.9 amps     Approx. 71dBA (High)

   Max Operating Temperature:
   Not to exceed 170 degrees Fahrenheit

   Warranty:
   Limited two-year warranty from date of shipment on defects due to materials or workmanship.

   Patented Design:
   U.S. PATENT #5,843,197

2000 Series


Loading the player...

2000 Series Ambient Air Collector Specifications

    Cabinet Dimensions:     Cabinet Material:
     - 45"L x 24"W x 24"H      - 16 ga. carbon steel w/ polyester epoxy coating on all surfaces
    Air Volume: Up to 2000 CFM     Total Weight: Approx. 115 lbs.
    Motor: Fractional Horsepower 3/4

   Available Filter Efficiencies:

   *MERV 7 Pre-filter up to 70% efficient at 3 microns and larger
   *MERV 14 Main Filter ASHRAE Bag up to 95% efficient at.3 microns and larger

   Electrical:    Sound Level:
    115/1/60, 8.7 amps     66 to 70 dba (Blower Speed: Low to High) at 6'

   Max Operating Temperature:
   Not to exceed 170 degrees Fahrenheit

   Warranty:
   Limited two-year warranty from date of shipment on defects due to materials or workmanship.

   Patented Design:
   U.S. PATENT #5,843,197

Ambient Air Cleaner features and benefits

  • Easy Access to Filters
  • Adjustable Grill
  • Quiet Operation
  • Reliable, Low Maintenance Operation
  • Low Power Consumption
  • Simple, Quick "No Tool" Filter Change
  • Long Filter Life
  • Sturdy Construction

Applications

Welding Workshops
Automotive Shops
Manufacturing Areas
Woodshops
Community Buildings
Offices
Cafeterias
Sports Facilities
Sanding
Buffing
Grinding Applications
Light Welding
Automotive Refinishing

Resources

Accessories

Additional Configuration - Side Exhaust
Fume Extractor Stand - SS-091-FES
7.5 ft height stand for elevated mounting.
