Industrial Fume Extractor

Sentry Air Systems offers a wide variety of chemical fume extraction equipment for the removal and purification of chemical fumes and vapors to assist in protecting the respiratory zone of those working with hazardous compounds and solutions. Typical applications include solvent-based cleaning or rinsing, formaldehyde, epoxies and resins, plastic bonding and gluing, touch-up painting, melting plastics, acid etching and a variety of applications involving chemical and solvent fumes, vapors, and chemical dusts.

Model # SS-XXX-XXX

Features and Benefits

  • Variable Speed Controller Included (115V only)
  • Magnehelic Gage Included]
  • Cleanable Filters
  • Reliable, Low Maintenance Operation
  • Heavy-Duty Casters & Portability Handles
  • 360° Rotating Source-Capture Arm
  • No Exterior Ducting Required
  • Long Filter Life
  • Simple "No Tool" Filter Change

Available Filters

  • (4) Micro-Pleat
    Series 1 Particulate Filters (MERV 13 efficiency rating)
  • (4) HEPA Filters
    (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
  • (4) 42 lb. Activated Carbon Filters
    (efficiency varies depending on application)
  • (4) 42lb. Specialty Blended Carbon Filters
    Double filters with HEPA and Carbon Available

Product Video

Standard

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- 7” Diameter, 7’ L
- Rigid segment: Aircraft-grade aluminum
- 6” diameter Flexible segment: Black Flex Sentry™
- 10" round capture hood

Total Weight:
Approximately 225lbs without Filters
Approximately 317lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
Fractional Horsepower

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters
just Double filters with HEPA and Carbon Available

Air Volume:
Up to 785 CFM High

Electrical:
115/1/60, 2.5 amps
220/1/50, 1.5 amps

Sound Level:
65 dba @ 3 ft.

Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

High Flow

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- 7” Diameter, 7’ L
- Rigid segment: Aircraft-grade aluminum
- 6” diameter Flexible segment: Black Flex Sentry™
- 10" round capture hood

Weight:
Approximately 240lbs without Filters
Approximately 332lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
1.5 HP

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters Double filters with HEPA and Carbon Available

Air Volume:
Up to 1060 CFM High

Electrical:
115/1/60, 10.7 amps
220/1/50, 5.35 amps

Sound Level:
72 dba @ 3 ft.

Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

Product Video

Standard

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- (2)7” Diameter, 7’ L
- Rigid segment: Aircraft-grade aluminum
- 6” diameter Flexible segment: Black Flex Sentry™
- 10" round capture hood

Total Weight:
Approximately 265lbs without Filters
Approximately 345lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
Fractional Horsepower

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters
just Double filters with HEPA and Carbon Available

Air Volume:
Up to 700 CFM High

Electrical:
115/1/60, 2.5 amps
220/1/50, 1.5 amps

Sound Level:
65 dba @ 3 ft.

Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

High Flow

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- 7” Diameter, 7’ L
- Rigid segment: Aircraft-grade aluminum
- 6” diameter Flexible segment: Black Flex Sentry™
- 10" round capture hood

Total Weight:
Approximately 360lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
1.5 HP

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters Double filters with HEPA and Carbon Available

Air Volume:
Up to 910 CFM High

Electrical:
115/1/60, 10.7 amps
220/1/50, 5.35 amps

Sound Level:
72 dba @ 3 ft.

Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

Product Video

Standard

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- 10’ L
- Rigid segment: Aircraft-grade aluminum
- 7” diameter Flexible segment: Black Flex Sentry™
- 10.5" round capture hood

Total Weight:
Approximately 225lbs without Filters
Approximately 317lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
Fractional Horsepower

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters
just Double filters with HEPA and Carbon Available

Air Volume:
Up to 730 CFM High

Electrical:
115/1/60, 2.5 amps
220/1/50, 1.5 amps

Sound Level:
65 dba @ 3 ft.

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

High Flow

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- 10’ L
- Heavy Duty Rigid segment: Aircraft-grade aluminum
- 7” diameter Flexible segment: Black Flex Sentry™
- 10" round capture hood

Weight:
Approximately 240lbs without Filters
Approximately 360lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
1.5 HP

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters Double filters with HEPA and Carbon Available

Air Volume:
Up to 995 CFM High

Electrical:
115/1/60, 10.7 amps
220/1/50, 5.35 amps

Sound Level:
72 dba @ 3 ft.

Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

Product Video

Standard

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- (2)10’ L
- Rigid segment: Aircraft-grade aluminum
- 6” diameter Flexible segment: Black Flex Sentry™
- 10" round capture hood

Total Weight:
Approximately 300lbs without Filters
Approximately 350lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
Fractional Horsepower

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters
just Double filters with HEPA and Carbon Available

Air Volume:
Up to 900 CFM High

Electrical:
115/1/60, 2.5 amps
220/1/50, 1.5 amps

Sound Level:
65 dba @ 3 ft.

Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

High Flow

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- (2) 10’ L
- Rigid segment: Aircraft-grade aluminum
- 6” diameter Flexible segment: Black Flex Sentry™
- 10" round capture hood

Total Weight:
Approximately 330lbs without Filters
Approximately 380lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
1.5 HP

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters Double filters with HEPA and Carbon Available

Air Volume:
Up to 1200 CFM High

Electrical:
115/1/60, 10.7 amps
220/1/50, 5.35 amps

Sound Level:
72 dba @ 3 ft.

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

Product Video

Standard

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- 6" Diameter x 12' Length
- Hose w/ Magnetic Capture Hood and Handle
- Optional 25 ft. Hose Available

Total Weight:
Approximately 210lbs without Filters
Approximately 280lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
Fractional Horsepower

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters
just Double filters with HEPA and Carbon Available

Air Volume:
Up to 430 CFM High

Electrical:
115/1/60, 2.5 amps
220/1/50, 1.5 amps

Sound Level:
65 dba @ 3 ft.

Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

High Flow

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- 6" Diameter x 12' Length
- Hose w/ Magnetic Capture Hood and Handle
- Optional 25 ft. Hose Available

Weight:
Approximately 210lbs without Filters
Approximately 280lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
1.5 HP

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters Double filters with HEPA and Carbon Available

Air Volume:
Up to 655 CFM High

Electrical:
115/1/60, 10.7 amps
220/1/50, 5.35 amps

Sound Level:
72 dba @ 3 ft.

Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

Product Video

Standard

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- (2)5" Diameter x 12' Length
- Hose w/ Magnetic Capture Hood and Handle
- Optional 25 ft. Hose Available

Total Weight:
Approximately 190lbs without Filters
Approximately 282lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
1.5 HP

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters
just Double filters with HEPA and Carbon Available

Air Volume:
900 CFM (450 per Hose)

Electrical:
115/1/60, 2.5 amps
220/1/50, 1.5 amps

Sound Level:
65 dba @ 3 ft.

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

High Flow

Cabinet Dimensions:
- 30” D x 30” W x 42.5” H

Arm Specifications:
- (2)5" Diameter x 12' Length
- Hose w/ Magnetic Capture Hood and Handle
- Optional 25 ft. Hose Available

Weight:
Approximately 210lbs without Filters
Approximately 280lbs with Filters Installed

Cabinet Material:
16 ga. carbon steel

Motor:
1.5 HP

Available Filter Efficiencies:
(4) Micro-Pleat Series 1 Particulate Filters (MERV 13 efficiency rating)
(4) HEPA Filters (Up to 99.97% efficient on particles down to 0.3 microns) Non-Cleanable
(4) 42 lb. Activated Carbon Filters (efficiency varies depending on application)
(4) 42lb. Specialty Blended Carbon Filters Double filters with HEPA and Carbon Available

Air Volume:
1300 CFM (650 per hose)

Electrical:
115/1/60, 10.7 amps
220/1/50, 5.35 amps

Sound Level:
72 dba @ 3 ft.

Warranty: Limited two-year warranty from date of shipment on defects due to materials or workmanship.

Patented Design:
U.S. PATENT #61,563,228 Pending

Quick Compare

Industrial Fume Extractor
7' Arm
Industrial Fume Extractor
Dual 7'
Industrial Fume Extractor
10' Arm
Industrial Fume Extractor
Dual 10'
Industrial Fume Extractor
Python Hose
Industrial Fume Extractor
Dual Python
Cabinet Dimensions: 30” D x 30” W x 42.5” H 30” D x 30” W x 42.5” H 30” D x 30” W x 42.5” H 30” D x 30” W x 42.5” H 30” D x 30” W x 42.5” H 30” D x 30” W x 42.5” H
CFM 65 dba @ 3 ft. 65 dba @ 3 ft. 65 dba @ 3 ft. 65 dba @ 3 ft. 65 dba @ 3 ft. 65 dba @ 3 ft.
Filter Size Extra Large | Cleanable Extra Large | Cleanable Extra Large | Cleanable Extra Large | Cleanable Extra Large | Cleanable Extra Large | Cleanable
Weight:
(with filters)
500: Approx. 240 lbs
550: Approx. 332 lbs
500: Approx. 345 lbs
550: Approx. 360 lbs
500: Approx. 240 lbs
550: Approx. 332 lbs
500: Approx. 345 lbs
550: Approx. 360 lbs
500: Approx. 190 lbs
500: Approx. 282 lbs
500: Approx. 190 lbs
550: Approx. 282 lbs
Electrical 500:
115/1/60, 2.5 amps
220/1/50, 1.5 amps
550:
115/1/60, 10.7 amps
220/1/50, 5 amps
500:
115/1/60, 2.5 amps
220/1/50, 1.5 amps
550:
115/1/60, 10.7 amps
220/1/50, 5 amps
500:
115/1/60, 2.5 amps
220/1/50, 1.5 amps
550:
115/1/60, 10.7 amps
220/1/50, 5 amps
500:
115/1/60, 2.5 amps
220/1/50, 1.5 amps
550:
115/1/60, 10.7 amps
220/1/50, 5 amps
500:
115/1/60, 2.5 amps
220/1/50, 1.5 amps
550:
115/1/60, 10.7 amps
220/1/50, 5 amps
500:
115/1/60, 2.5 amps
220/1/50, 1.5 amps
550:
115/1/60, 10.7 amps
220/1/50, 5 amps
Sound Level 65 dba @ 3 ft. 65 dba @ 3 ft. 65 dba @ 3 ft. 65 dba @ 3 ft. 65 dba @ 3 ft. 65 dba @ 3 ft.

Accessories

Spark Reducer
Industrial Fume Extractor

SS-006-SR
Reduces sparks from entering the unit

Remote Control Box
Industrial Fume Extractor

SS-400-RCB
Controls unit operation remotely.

Configurations

Activated Carbon Filtration
Activated Carbon Filtration

SS-500-PYT-240CFC

Brochure
Model 550 Dual Stand Assembly
Model 550 Dual Stand Assembly

SS-550-STHD2-MP1

Brochure

Applications

  • Welding
  • Metal Fabrication
  • Large Scale Factories
  • Woodworking
  • Sanding
  • Grinding
  • Automotive
  • Buffing
  • Refinishing
  • Brazing
  • Soldering
  • Commercial

Cleaning the Filters

The Micro-Pleat Series 1 Particulate Filters are engineered to be easily cleaned with the use of pressurized air. This form of self-contained cleaning does not require removal of the filters; the operator simply sprays air into the filter media to clean and rejuvenate them while excess dust a nd waste falls into the internal dust pan, allowing for simple and clean debris removal. The included magnehelic gage is an excellent tool for determining filter saturation. Once the pressure levels begin to increase, the operator can clean the filters and the pressure reduction will be noted on the gage.
