Ambient Air Cleaner
The Ambient Air Cleaner is a commercial-grade air filtration system that is highly effective at removing ambient pollutants without the need for external ducting, or make-up air. These low-maintenance filtration systems can be conveniently mounted in the desired ceiling location without taking any floor space, and in certain applications can be mounted on a stand. Typically used in locations where outside ventilation cannot suffice, ambient air cleaners are utilized to remove toxins, pollutants, and contaminants from the atmosphere.
700 Series
700 Series Ambient Air Collector Specifications
| Cabinet Dimensions: |
Cabinet Material: |
| - 32 5/8"W x 24 3/4"D x 14.5"H |
- 16 ga. Carbon Steel, Powder Coated |
| Air Volume: Up to 100 CFM |
Total Weight: 132 - 160 lbs. (Varies depending on filter media installed) |
| Motor: Fractional Horsepower 3/4 |
|
Available Filter Efficiencies:
HEPA Filter - Up to 99.97% efficient on particles down to 0.3 microns in size.
ASHRAE Filter - Up to 95% efficient on particles down to 0.5 microns in size.
ULPA Filter - Up to 99.9995% efficient on particles down to 0.12 microns in size.
Activated Carbon & Specialty-Blended Filters - Efficiency varies per chemical.
| Electrical: |
Sound Level: |
| 115/1/60, 4.9 amps |
Approx. 71dBA (High) |
Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit
Warranty:
Limited two-year warranty from date of shipment on defects due to materials or workmanship.
Patented Design:
U.S. PATENT #5,843,197
2000 Series
2000 Series Ambient Air Collector Specifications
| Cabinet Dimensions: |
Cabinet Material: |
| - 45"L x 24"W x 24"H |
- 16 ga. carbon steel w/ polyester epoxy coating on all surfaces |
| Air Volume: Up to 2000 CFM |
Total Weight: Approx. 115 lbs. |
| Motor: Fractional Horsepower 3/4 |
|
Available Filter Efficiencies:
*MERV 7 Pre-filter up to 70% efficient at 3 microns and larger
*MERV 14 Main Filter ASHRAE Bag up to 95% efficient at.3 microns and larger
| Electrical: |
Sound Level: |
| 115/1/60, 8.7 amps |
66 to 70 dba (Blower Speed: Low to High) at 6' |
Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit
Warranty:
Limited two-year warranty from date of shipment on defects due to materials or workmanship.
Patented Design:
U.S. PATENT #5,843,197
Ambient Air Cleaner features and benefits
- Easy Access to Filters
- Adjustable Grill
- Quiet Operation
- Reliable, Low Maintenance Operation
- Low Power Consumption
- Simple, Quick "No Tool" Filter Change
- Long Filter Life
- Sturdy Construction
Applications
| Welding Workshops |
Automotive Shops |
| Manufacturing Areas |
Woodshops |
| Community Buildings |
Offices |
| Cafeterias |
Sports Facilities |
| Sanding |
Buffing |
| Grinding Applications |
Light Welding |
| Automotive Refinishing |
Resources
Accessories
Additional Configuration - Side Exhaust
Fume Extractor Stand - SS-091-FES
7.5 ft height stand for elevated
mounting.
